DHW cylinder
SBB 1000 WP SOL – Technical Data

  • Technical data

    Nominal capacity

    835 l

    Surface area, heat exchanger, top

    6.20 m²

    Surface area, heat exchanger, bottom

    3.60 m²

    Height

    2153 mm

    Diameter incl. thermal insulation

    1,010 mm

    Height when tilted

    2,185 mm

    Weight

    321 kg

    Technical data and product variants

    For further details and product variants please refer to data sheet.

    Download as PDF

Installation Information:

Please ask your local power supply utility or a registered electrician to install appliances that are not fully wired, i.e. ready to plug in. The electrician should also be able to assist you with obtaining the agreement of the respective power supply utility required for the appliance installation.
